Fiber Optical cable connector box RM-GPJ

Short Description:

The product plays the role of protective sealing, welding and storage for connected optical cables, and is suitable for direct and branch connection of optical cables. This series of joint box has wide application range, good sealing performance, and can be used in wall-mounted, overhead, direct-buried, pipeline Wells, etc.

We are the Factory that guarantees supply chain and product quality

Acceptance: Distribution, Wholesale,Custom,OEM/ODM

We are China’s famous sheet metal factory, is your trusted partner

We have a big brand of cooperative production experience(You’re next)

Any inquiries→ We are happy to reply, please send your questions and orders

No MOQ limit,any installation can be communicated at any time


Product Detail

Product Tags

The RM-GFJ series fiber optic cable connector box is an indispensable supporting equipment in the fiber optic cable line. The product plays a protective sealing, fusion, and storage function for the connected fiber optic cable, and is suitable for direct and branch connections of the fiber optic cable. Widely applicable, with good sealing performance, this series of joint boxes can be used in wall mounted, overhead, direct buried, and pipeline wells. The joint boxes are divided into horizontal (Huff type) structures and split cap (vertical) structures, and currently have multiple specifications to meet the needs of different numbers of cables entering and exiting.

Work environment indicators

  • Environmental temperature: -40 ℃~+60 ℃
  • Atmospheric pressure: 70-106Kpa
  • Tensile strength: > 1000N
  • Anti pressure: > 2000N/10 cm ² Pressure, time 1min
  • Withstand voltage strength: 15KV (DC)/1min, no breakdown, no flashover
  • Insulation resistance: > 2 × 104 MΩ

Application Scenario

This series of products is suitable for outdoor aerial, outdoor hanging poles, underground electric wells, and pipeline scenarios. It has high waterproof and dustproof performance, and the material has strong UV resistance and weather resistance. This series of products adopts a waterproof structure design, with excellent sealing performance and a service life of over 20 years.

PM72

Product Features

  • The box body is injection molded with special plastic added with anti-aging agent and anti ultraviolet radiation materials, which has high anti-aging and anti ultraviolet capabilities and extends the service life
  • The split cap type adopts a plastic hoop locking device, without the need for screws to tighten; Mechanical seal, heating and contraction type, with good sealing performance and simple operation
  • The Huff style structure adopts multiple locking points for high sealing performance
  • Reliable sealing performance, easy to open repeatedly, high strength, direct burial or overhead installation, reliable grounding protection
  • Adopting a large fused fiber disc structure with a curvature radius of>40mm
  • The aging life of the shell is over 20 years
  • Convenient installation, no special construction training required for construction operations, with openable devices for easy repeated opening

Series Products

RM-GPJ-01

RM-GPJ_Series-Products-18

RM-GPJ-02

RM-GPJ_Series-Products-17

RM-GPJ-03

RM-GPJ_Series-Products-15

RM-GPJ-04

RM-GPJ_Series-Products-13

RM-GPJ-05

RM-GPJ_Series-Products-12

RM-GPJ-06

RM-GPJ_Series-Products-11

RM-GPJ-07         RM-GPJ_Series-Products-10

RM-GPJ-08RM-GPJ_Series-Products-9

RM-GPJ-09

RM-GPJ_Series-Products-8

RM-GPJ-10

RM-GPJ_Series-Products-7

RM-GPJ-11

RM-GPJ_Series-Products-6

RM-GPJ-12

RM-GPJ_Series-Products-5

RM-GPJ-13

RM-GPJ_Series-Products-4

RM-GPJ-14

RM-GPJ_Series-Products-3

RM-GPJ-15

RM-GPJ_Series-Products-1

RM-GPJ-16

RM-GPJ_Series-Products-19

RM-GPJ-17

RM-GFX_Series Products1701

Packing list

This RM-GPJ series of products adopts standard corrugated cardboard boxes, with fumigated wooden trays at the bottom and protective film wrapped on the outer layer

RM-L925_Packaging 1

Product Services

RM-ZHJF-PZ-4-26

After sales service: This series of products comes in various models, suitable for various types of optical cables and various scenarios. Please consult our sales personnel for specific models. For contact information, please refer to the contact channels on our official website

RM-ZHJF-PZ-4-27

Standard service: This series of products is a standardized product suitable for the construction of fiber optic communication networks in various countries around the world. If you need to learn more about fiber optic systems or other extended products, please contact our customer service personnel, and we will do our best to answer and serve you

RM-ZHJF-PZ-4-25

Instructions for use: For customers who have already reached a cooperation agreement, if you encounter any technical problems during the use process, you can consult our sales personnel 7 * 24 hours. We will wholeheartedly serve you and provide the most professional technical guidance
